FABRIC MACE SNAG TESTER SX-FZ23
Application:
It is suitable for knitted fabrics, woven fabrics and other fabrics that are easy to hook, especially for testing the hook degree of chemical fiber filament and textured yarn fabric.
Standards: ASTM D3939, JIS L1058, GB/T 11047, MN405E
Specification:
- fabric hook drum: 4 PCS; Hammer: 4 PCS
- hammer mass: 160±10g, hammer needle number 11,
- counting range: 0 ~ 99999 (LCD)
- Drum diameter: 82mm, width: 210mm, of which the outer rubber thickness is 3mm
- relative speed: 60±2 RPM
- felt thickness 3-3.2mm, width: 165mm
- guide bar working width: 125mm
- Distance between hammer and guide rod: 45mm
- Power: AC220V, 50Hz,
